Laser Safety Products

  • ICS-7-OEM Interlock Controller

    An OEM version of ICS Interlock®

    Lasermet’s established and proven ICS Interlock® control system is available as an OEM version which is specifically designed for integrators to use as part of the laser control system.

    • Dual-channel safety
    • Ready to use with PLC controllers
    • Fail-safe reliability
    • Compatible with expansion modules
  • ICS-9 Interlock® Controller

    NRTL Certified Laser Interlock® Control System

    The ICS-9 Laser Interlock® Controller is the successor to the highly successful ICS-6, directly replacing it.

    • Full start-to-end dual channel architecture and fault detection
    • Interlocked mains supply
    • Interlocked low voltage supply for beam shutters
    • Laser Interlock® connector operators for all lasers
    • Time limited fail-safe override option
    • Automatic switching of illuminated signs indicating danger or safe modes
    • Emergency stop circuit to prevent injury or damage in an emergency
  • ICS-DB-2-0 Interlock Interface

    ICS-DB-2/0

    Distribution Box

    The ICS-DB-2/0 distribution box has can accommodate two interlock output connections (laser connection).

  • ICS-DB30-0/2

    Distribution Box

    The ICS-DB30-0/2 distribution box has can accommodate two Lasermet beam shutter connections.

  • ICS-DB30-1-1 Laser Shutter Interlock 1

    ICS-DB30-1/1

    Distribution Box

    The ICS-DB30-1/1 distribution box can accommodate one Lasermet beam shutter and one interlock output (laser connection).

  • ICS-DBS-IC Interlock2

    ICS-DBS-IC

    Switched Distribution Box

    Lasermet’s ICS-DBS-IC switched interlock distribution box allows you to easily arm and disarm your connected laser.

  • ICS-SOLO Low-cost Laser Interlock® Controller

    Ideal for Hand-held Laser Welding Enclosures

    The ICS-SOLO is a low-cost, dual-channel laser safety interlock controller ideal for handheld laser welding enclosures. It is a single input, single output laser safety controller typically used in small laser safety enclosures with a single door and controlling a single laser. The ICS-SOLO is a dual channel device which means that there are two input switches that must both be closed for the laser to be enabled.

    This is achieved using Lasermet’s dual channel door interlock switch. ICS-SOLO has a simple, easy-to-use control panel which can be wired directly to the dual channel switch on the interlocked door and to the laser, keyswitch, emergency stops, and LED Warning Sign.

  • ICS-TOUCH

    Interlock® Control System for Operating Theatres



    The ICS-TOUCH provides touchscreen monitoring and control for operating theatres and X-ray machines.



    • Easy-to-use touchscreen technology
    • Interlocked Doors, Roller Blinds and Emergency Stops
    • Flush-fit to wall or door
    • Full dual channel safety to ISO 13849-1 Performance Level ‘e’ (PL ‘e’)
    • Secure Access Keypad Lock



  • IS-MDC-12 Interlock® Switch

    Dual Channel Interlock® Switch

    Lasermet’s IS-MDC-12 is a dual channel coded magnetic door safety contact, which is used to detect when a door or other moveable cover forming part of a protective enclosure is open.

    • Achieve Performance Level ‘e’ as specified in BS EN 13849-1:2008
    • Small, sleek, and compact package
    • CE and UKCA marked
  • Laser Blocking Roller Blinds

    Protection from Stray Laser Radiation

    Lasermet’s laser blocking roller blinds are designed as a passive guarding system to block laser light from escaping the theatre, laboratory or laser facility where Class 3B or Class 4 lasers are in use, either to protect against accidental exposure to the laser beam or for long term blocking of laser radiation at lower power densities.

  • Laser Blocking Screens

    Safety Screens

    To protect personnel from Class 4 and Class 3B lasers it is imperative to have comprehensive laser safety protection in place. Laser radiation must be prevented from escaping from labs and manufacturing facilities using certified equipment.

    • Portable
    • Lightweight
    • High Specification Protection
    • CE marked and certified to BS EN IEC 60825-4 Safety of Laser Products Part 4: Laser Guards
  • Laser Castle Passive Laser Safety Cabin

    Laser Castle

    Passive Laser Safety Cabin

    Lasermet’s Laser Castle® laser safety cabins protect personnel from the dangers of high powered laser beams by absorbing the laser power in the specially designed walls and roof. These modular, Class 1, room-sized enclosures are tested and certified to international laser safety standards and can be rapidly designed, built and installed by Lasermet.

    • Rapid-build modular laser safety cabins
    • Passive Class 1 Enclosures for Class 4 lasers
    • CE Certified to EN IEC 60825-4 Safety of Laser Products Part 4 – Laser Guards
  • Lasermet Laser Castle for laser safety

    Laser Castle Lite

    Self-build Laser Safety Enclosure

    The Laser Castle Lite is a self-build miniature version of Lasermet’s Laser Castle Cabin. The Laser Castle Lite is a low-cost modular enclosure that is easy to build and deploy on site.

    • Ideal for hand-held lasers and small laser robots
    • Interlock® ready
    • Low-cost modular safety solution
    • Self-assembly
  • Laser Filter Windows

    Laser Safety Viewing Windows

    Laser viewing windows enable you to see inside an enclosure while stopping the laser radiation from coming out, thus providing protection with the minimum of inconvenience.

    These viewing windows are available for a wide variety of different types of lasers and can be made of either plastic or mineral glass.

  • Laser Jailer Active Laser Safety System by Lasermet

    Laser Jailer

    Active Laser Guarding Safety System

    The Laser Jailer combines an inherently fail-safe laser detection technique and Lasermet’s proven laser Interlock® control system technology to create an active laser guarding system conforming to Machinery Directive Standard EN 13849-1.

    • Active and Passive Laser Enclosures
    • Lightweight, modular, scalable
    • Retrofit to existing rooms and enclosures
    • Rapid turnkey solution
    • Conforms to laser safety standards EN/IEC 60825-1 and ANSI Z136.1
  • Laser Warning Labelling

    Laser Warning Labels to Current Laser Safety Standards

    All labels are printed on durable self-adhesive vinyl, with the correct colouring, wording, symbols and layout as defined in the European, International or US standards.
