Weatherproof IP66 LED Ultra Signs

IP66 Weatherproof LED Signs for Outdoor Use

Lasermet’s Ultra Signs now come in an IP66-rated weatherproof version for use in outdoor environments. Seamless graphics with the backlit LED design set this sign apart from pixelated matrix LED displays.

  • Weatherproof sign for outdoor use (IP66)
  • Any message, graphic, or language
  • Single or dual message
  • Low voltage 24VDC (48VDC optional)
  • DALI Interface option

Description

IP66 rated Ultra Signs for Outdoor Use

The LED Ultra 580 is the professional IP66 rated LED sign for outside use. UK manufactured, these dual-message, dual-colour, DALI compatible signs are low voltage 24VDC (48VDC option available on request).

Being IP66 rated to BS EN IEC 60529, these Ultra Signs are protected against powerful water jets and is dust-tight – ideal for use in the wind and rain. The high-brightness LEDs ensure the sign is readable in strong sunlight and bad weather too.

Other options, to be specified when ordering, include auto or remote dimming, on/off flashing capability, and DALI compatible module options. DALI is the Digitally Addressable Lighting Interface standard used in the lighting industry.

A number of mounting bracket options are available for either single facing or dual facing signs, in addition to direct wall mounting.

Specifications

Size580 x 178 x 26.8 mm
Weight2.8 kg
Operating Voltage18 – 26 VDC
ComplianceBS EN 60529:1992 + A2:2013 – IP66
BS EN 60598-1:2008
EN 62471:2008
EN 55015:2013 +A1:2015
EN 61547:2009
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
CE Directive 2006/42/EC

Ordering Options

Part NumberDescriptionColours Available
LEDS-ULT-580-IP66-YWithout Overlay (Custom message)yellow 1 by Lasermet Laser Safety Solutions yellow
LEDS-ULT-580-IP66-BWithout Overlay (Custom message)blue by Lasermet Laser Safety Solutions blue
LEDS-ULT-580-IP66-RWithout Overlay (Custom message)red by Lasermet Laser Safety Solutions red
LEDS-ULT-580-IP66-RGWithout Overlay (Custom message)redgreen by Lasermet Laser Safety Solutions red/green

Part Numbers may vary depending on the chosen color.
