Slim Jim LED SignThe Thin Profile Backlit LED Sign
- High Quality – smart appearance
- Only 11mm thick
- 230V AC or 110V AC
- No transformer
- Fits to existing mains power, single or twin socket back-boxes
- Fits to conduit boxes
- Cheaper and faster installation
- Current 40 mA (230 VAC), 80mA (110 VAC)
- DALI compatible – (Digital Addressable Lighting Interface)
- Contractor friendly
- Overall dimensions 355 x 105 x 11mm
- Sign dimensions 275 x 58mm
Slim Jim is the thin profile backlit LED sign from Lasermet.
Measuring approximately 11mm thick, this extremely thin LED sign runs directly from 230 VAC mains power with no additional power supply or transformer.
It fits neatly onto the UK, US and European mains power single and double socket back-boxes as well as the standard conduit boxes making it easy and quick to fit for contractors.
Exploded view of Slim Jim LED Sign
The Slim Jim LED sign is just 11mm thick
It has the option to be compatible with the DALI technical standard IEC 62386 (Digital Addressable Lighting Interface) which enables the sign to be controlled centrally.
The optional DALI compatible module sits in the 35mm back box.
DALI compatible module
Ordering information
• Slim Jim LED Signs are available with text/graphics in a single colour
– either Red or Yellow or Blue. They are all powered by mains 230 VAC.
• There is an option to have the surround in stainless steel instead of the standard
white powder-coated finish.
• The separate DALI compatible module Part No. is DALI -1 for 230 VAC or
DALI-2 for the 110 VAC version
• For custom wording/graphics there is an artwork origination charge.
Buy Slim Jim LED Signs online
You can either Buy online or contact Lasermet for details or select the part number you require and email your enquiry to sales@lasermet.com
| Appearance | Message | Part Number | Options |
|
|
DO NOT ENTER | LEDS-SJ-R-DNE | Red |
| LEDS-SJ-Y-DNE | Yellow | ||
| LEDS-SJ-B-DNE | Blue | ||
| LEDS-SJ-SS-R-DNE | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-DNE | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-DNE | Blue, Stainless Steel | ||
 |
In Use | LEDS-SJ-R-IU | Red |
| LEDS-SJ-Y-IU | Yellow | ||
| LEDS-SJ-B-IU | Blue | ||
| LEDS-SJ-SS-R-IU | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-IU | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-IU | Blue, Stainless Steel | ||
 |
Lab in Use | LEDS-SJ-R-LIU | Red |
| LEDS-SJ-Y-LIU | Yellow | ||
| LEDS-SJ-B-LIU | Blue | ||
| LEDS-SJ-SS-R-LIU | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-LIU | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-LIU | Blue, Stainless Steel | ||
 |
Laser in Use | LEDS-SJ-R-LAS | Red |
| LEDS-SJ-Y-LAS | Yellow | ||
| LEDS-SJ-B-LAS | Blue | ||
| LEDS-SJ-SS-R-LAS | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-LAS | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-LAS | Blue, Stainless Steel | ||
 |
Laser On | LEDS-SJ-R-LO | Red |
| LEDS-SJ-Y-LO | Yellow | ||
| LEDS-SJ-B-LO | Blue | ||
| LEDS-SJ-SS-R-LO | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-LO | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-LO | Blue, Stainless Steel | ||
 |
LASER RADIATION | LEDS-SJ-R-LR | Red |
| LEDS-SJ-Y-LR | Yellow | ||
| LEDS-SJ-B-LR | Blue | ||
| LEDS-SJ-SS-R-LR | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-LR | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-LR | Blue, Stainless Steel | ||
 |
NO ENTRY | LEDS-SJ-R-NE | Red |
| LEDS-SJ-Y-NE | Yellow | ||
| LEDS-SJ-B-NE | Blue | ||
| LEDS-SJ-SS-R-NE | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-NE | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-NE | Blue, Stainless Steel | ||
 |
OCCUPIED | LEDS-SJ-R-OC | Red |
| LEDS-SJ-Y-OC | Yellow | ||
| LEDS-SJ-B-OC | Blue | ||
| LEDS-SJ-SS-R-OC | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-OC | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-OC | Blue, Stainless Steel | ||
 |
Room In Use | LEDS-SJ-R-RIU | Red |
| LEDS-SJ-Y-RIU | Yellow | ||
| LEDS-SJ-B-RIU | Blue | ||
| LEDS-SJ-SS-R-RIU | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-RIU | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-RIU | Blue, Stainless Steel | ||
 |
X-RAYS ON | LEDS-SJ-R-XR | Red |
| LEDS-SJ-Y-XR | Yellow | ||
| LEDS-SJ-B-XR | Blue | ||
| LEDS-SJ-SS-R-XR | Red, Stainless Steel | ||
| LEDS-SJ-SS-Y-XR | Yellow, Stainless Steel | ||
| LEDS-SJ-SS-B-XR | Blue, Stainless Steel |
The following Part numbers are for the US market using 110VAC
| Appearance | Message | Part Number for 110 VAV signs | Options |
|
|
DO NOT ENTER | LEDS-SJ-110-R-DNE | Red |
| LEDS-SJ-110-Y-DNE | Yellow | ||
| LEDS-SJ-110-B-DNE | Blue | ||
| LEDS-SJ-110-SS-R-DNE | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-DNE | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-DNE | Blue, Stainless Steel | ||
|
In Use | LEDS-SJ-110-R-IU | Red |
| LEDS-SJ-110-Y-IU | Yellow | ||
| LEDS-SJ-110-B-IU | Blue | ||
| LEDS-SJ-110-SS-R-IU | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-IU | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-IU | Blue, Stainless Steel | ||
|
Lab in Use | LEDS-SJ-110-R-LIU | Red |
| LEDS-SJ-110-Y-LIU | Yellow | ||
| LEDS-SJ-110-B-LIU | Blue | ||
| LEDS-S-110J-SS-R-LIU | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-LIU | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-LIU | Blue, Stainless Steel | ||
|
Laser in Use | LEDS-SJ-110-R-LAS | Red |
| LEDS-SJ-110-Y-LAS | Yellow | ||
| LEDS-SJ-110-B-LAS | Blue | ||
| LEDS-SJ-110-SS-R-LAS | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-LAS | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-LAS | Blue, Stainless Steel | ||
|
Laser On | LEDS-SJ-110-R-LO | Red |
| LEDS-SJ-110-Y-LO | Yellow | ||
| LEDS-SJ-110-B-LO | Blue | ||
| LEDS-SJ-110-SS-R-LO | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-LO | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-LO | Blue, Stainless Steel | ||
|
LASER RADIATION | LEDS-SJ-110-R-LR | Red |
| LEDS-SJ-110-Y-LR | Yellow | ||
| LEDS-SJ-110-B-LR | Blue | ||
| LEDS-SJ-110-SS-R-LR | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-LR | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-LR | Blue, Stainless Steel | ||
|
NO ENTRY | LEDS-SJ-110-R-NE | Red |
| LEDS-SJ-110-Y-NE | Yellow | ||
| LEDS-SJ-110-B-NE | Blue | ||
| LEDS-SJ-110-SS-R-NE | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-NE | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-NE | Blue, Stainless Steel | ||
|
OCCUPIED | LEDS-SJ-110-R-OC | Red |
| LEDS-SJ-110-Y-OC | Yellow | ||
| LEDS-SJ-110-B-OC | Blue | ||
| LEDS-SJ-110-SS-R-OC | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-OC | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-OC | Blue, Stainless Steel | ||
|
Room In Use | LEDS-SJ-110-R-RIU | Red |
| LEDS-SJ-110-Y-RIU | Yellow | ||
| LEDS-SJ-110-B-RIU | Blue | ||
| LEDS-SJ-110-SS-R-RIU | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-RIU | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-RIU | Blue, Stainless Steel | ||
|
X-RAYS ON | LEDS-SJ-110-R-XR | Red |
| LEDS-SJ-110-Y-XR | Yellow | ||
| LEDS-SJ-110-B-XR | Blue | ||
| LEDS-SJ-110-SS-R-XR | Red, Stainless Steel | ||
| LEDS-SJ-110-SS-Y-XR | Yellow, Stainless Steel | ||
| LEDS-SJ-110-SS-B-XR | Blue, Stainless Steel |
Signs without overlays
All standard parts are made up from the signs without overlays, plus the overlay. Part numbers for Signs without overlays are as below:
| Type | Part No |
| 230 VAC Red | LEDS-SJ-R |
| 230 VAC Yellow | LEDS-SJ-Y |
| 230 VAC Blue | LEDS-SJ-B |
| 110 VAC Red | LEDS-SJ-110-R |
| 110 VAC Yellow | LEDS-SJ-110-Y |
| 110 VAC Blue | LEDS-SJ-110-B |
